Q281

A pair of smith's tongs is an example of the lever of

A.
Zeroth order
B.
First order
Answer
C.
Second order
D.
Third order

Answer: Option B

Solution

Answer: Option B
Solution:
Engineering Mechanics mcq solution image

First Order Levers: First class levers have the fulcrum between the force and the load. In using a screwdriver to lift the lid from a paint tin you are moving the effort over a greater distance than the load.

Second Order Levers: In second class levers the load is between the effort (force) and the fulcrum. A common example is a wheelbarrow where the effort moves a large distance to lift a heavy load, with the axle and wheel as the fulcrum.

Third-order levers: With third class levers the effort is between the load and the fulcrum, for example in barbecue tongs.

Source : primaryconnections.org.au
